The Male Elbow is a compact, rugged, and highly reliable pipe fitting designed to make 90-degree directional changes in piping systems — all while ensuring a secure, leak-tight connection. With a male-threaded end on one side and a female or male-threaded counterpart on the other, this elbow fitting becomes the perfect solution when space is limited, but performance is non-negotiable.
Crafted from durable materials like 316 stainless steel, brass, or carbon steel, male elbows are built to withstand demanding pressures, temperature variations, and corrosive environments. Whether you’re routing hydraulic lines in an industrial setup or aligning plumbing in residential systems, the male elbow brings flexibility and functionality to the forefront.
Its hexagonal body allows for easy wrenching, ensuring quick installation and tight sealing even in awkward or confined spots.
Product Data
- 90° Angle Design – Ideal for sharp directional changes in piping systems.
- Male Threaded End – Easily connects to female-threaded pipes or fittings.
- Compact & Space-Saving – Perfect for tight and confined installation areas.
- Durable Construction – Available in Stainless Steel, Brass, and Carbon Steel.
- Corrosion & Pressure Resistant – Suitable for harsh and high-pressure environments.
- Easy Wrenching Hex Body – Allows quick tightening and secure sealing.
- Versatile Thread Options – Compatible with NPT, BSPT, BSPP, and more.
- Leak-Proof Performance – Ensures secure and tight connections in fluid systems.
- Wide Application Range – Used in hydraulic, pneumatic, plumbing, and industrial systems.
- Available in Various Sizes – Fits multiple piping specifications from small to large diameters.
Technical Information :
- Material Options : SS 304, SS 316, SS 316L, Brass, Carbon Steel, Copper, Gunmetal / Bronze, Custom Alloys, other material on request
- Thread Types : NPT, BSP, BSPT, BSPP, Metric Threads
- Size Range : 1/16″ to 2″ for threaded ends (like NPT, BSPT, BSP) and 1/16″ OD to 2″ OD (or 3mm to 50mm) for tube ends
- Working Pressure: 200 PSI
- Temperature Range: -65°F to 250°F (-54°C to 121°C)
Applications of Male Elbow
- Plumbing Systems : For changing pipe direction in tight spaces and ensuring smooth water flow.
- Hydraulic & Pneumatic Systems : Essential in connecting actuators, valves, and pumps where fluid or air direction needs adjustment.
- Industrial Machinery & Equipment : Used to route process lines efficiently in compact mechanical assemblies.
- Oil & Gas Industries : Suitable for high-pressure piping to redirect flow safely in refineries and pipelines.
- HVAC Systems : Connects refrigerant and fluid lines at angles for space optimization in heating and cooling units.
