The Female Elbow is a vital component in the world of fluid and gas conveyance, where reliability, compact routing, and leak-proof connections matter most. Designed with female threads on both ends or one end (depending on type), it facilitates a secure 90-degree directional change in piping systems. This fitting is a preferred solution when space constraints or design layouts demand a tight bend without compromising flow integrity.
Crafted from robust materials such as 316 stainless steel, brass, or carbon steel, female elbows are built to withstand high pressures and varying temperatures, making them suitable for everything from hydraulic and pneumatic systems to chemical processing and HVAC setups.
Whether it’s connecting tubing in an instrumentation panel or redirecting flow in a complex plumbing network, the female elbow ensures a tight, corrosion-resistant, and long-lasting connection.
Product Data
- Threaded Female Ends – For easy and secure connection to male-threaded pipes.
- 90-Degree Angle Design – Efficiently changes direction in piping systems.
- Durable Construction – Made from strong materials (e.g., stainless steel, brass) to ensure long-lasting performance.
- Corrosion & Pressure Resistance – Handles harsh environments and high-pressure applications.
- Leak-Proof Connection – Ensures tight sealing to prevent fluid or gas leakage.
- Available in Various Sizes – Fits different piping needs and standards.
Technical Information :
- Material Options : SS 304, SS 316, SS 316L, Brass, Carbon Steel, Copper, Gunmetal / Bronze, Custom Alloys, other material on request
- Thread Types : NPT, BSP, BSPT, BSPP, Metric Threads
- Size Range : 1/16″, 1/8″, 1/4″, 3/8″, 1/2″, 3/4″, 1″, 1 1/4″, 1 1/2″, 2″, 2 1/2″, 3″, 4”
- Working Pressure: up to 60,000 PSI
- Temperature Range: -65°F to 250°F (-54°C to 121°C)
Applications of Female Elbow
- Plumbing Systems : Used to connect pipes at a 90° angle, especially in tight or corner spaces.
- Hydraulic Systems : Redirects fluid flow under high pressure in systems like presses, cranes, and machinery.
- Pneumatic Tools & Lines : Changes direction of compressed air flow in industrial automation and equipment.
- HVAC Systems : Connects refrigerant and fluid lines efficiently in heating and cooling installations.
- Instrumentation and Process Control : Ensures accurate directional connections in sensors, gauges, and flow meters.
